Description

High-Quality Components

Silent compressor: integrated KNF air compressor, providing you with quiet and comfortable treatment

Skillful accessories: high-quality workmanship of bullets and metal pipes, enabling the device to produce 2 million shocks

Various transmitters: 6 ballistic pneumatic transmitters, including Radial, Acupuncture, Deep and Focus, covering multiple sizes

Air tank: invisible design ensuring stable output and portable style

Metal trolley: lightweight and fashionable trolley facilitating device removal


Ergonomic Handpiece

Comfort: special ergonomic grip and elimination of backward shocks bringing you the most comfortable experience on the market

Safety: the safety switch is set in handpiece button, and the working state of the interface is locked, effectively avoiding misoperation

Convenience: the removable handpiece is convenient for daily cleaning and maintenance


Multiple Functions via USB

History download: patient file PDF output supported, device storage up to 5,000 documents

Software-update: unlimited upgrades software by USB disk


Visualized Therapy

User file downloading: patient database PDF output providing overall history review

Circumference record: curve diagram making all sessions at a glance


Preset Protocols with Image Guidance

Image guidance: large human body pictures visualizing treatment

Preset protocols: image-based treatment guidance, parameters based on clinical tests, one-touch-start treatment


OEM Available, After-sale Warranty

Two years warranty.

The device is customizable. You can customize the product in various ways, but the MOQ is required. Please contact us for more information.




APPLICATIONS

  • Body contouring
  • Cellulite treatment
  • Scarssmoothing
  • Blood circulation
  • Joint flexibility
  • Somatic stability
  • Circumference reduction
  • Skin elasticityimprovement
  • Muscle strength and endurance
  • Cardiopulmonary function
  • Sensory function
  • Balance ability
  • Exercise tolerance
  • Firming tissue
  • Treatment of pregnancy stretch marks

RESTRICTIONS

Patients with the following disease are forbidden to use:

  • Pregnant woman
  • Osteoporosis
  • Growing children
  • Coagulation defects
  • Bleeding tendency
  • Persons with pacemaker
  • Neoplasms
  • Cutaneous infections
  • Lung area
  • Spine area
  • Post operation (wound, exudation)
  • Cortisone therapy up to 6 weeks before first use the shockwave
  • Mental disorders (unable to express or have difficulty incommunication)

Channel1
CompressorIntegrated air compressor (KNF from Germany)
Interface7″ LCD touch screen
Pressure Range1.0 – 4.0 bar (adjustable by 0.1 bar)
Frequency Range1 – 17 Hz (adjustable by 1 Hz)
Pulse1-3000 (step by 100 pulses)
Dimension39.5(L) × 39(W) × 19.4(H) cm
Standard Weight10.5 kg
Preset ProtocolsYes
User-defined ProtocolsNo
Languages5 (English, German, French, Italian & Spanish)

STANDARD ACCESSORIES

PictureNameQuantity

General Handpiece

1 pc
15mm Radial Transmitter1 pc
20mm Radial Transmitter1 pc
36 mm Radial Transmitter1 pc
Revision Kit2 pcs

General Handpiece Kit

1 set


OPTIONAL ACCESSORIES

PictureNameQuantity
6 mm Acupuncture Transmitter1 pc
15 mm Deep Transmitter1 pc
15 mm Focus Transmitter1 pc
Trolley1 pc
Carrying Case1 pc

1.What is the difference between ultrasound and shock wave therapy?

The ultrasound treatment is gentler compared to shock wave therapy. And it only consists of one frequency, while a shock wave is a wave group made up of various frequencies, wavelengths, and speeds.

Shock wave treatment is more effective and doesn’t need everyday use, but ultrasound is required to use every day for better results.

2.How to avoid adverse reactions?

① Control intensity reasonably, and strenuous exercise is strictly prohibited within 24 hours after treatment.

② Hot compresses are strictly prohibited within 24 hours after treatment.

3.How many treatment sessions could cure the indications?

It varies from the severity of the patient and should be diagnosed by a professional therapist.
